11 Analyzing potential JVM issues with GC logs

Garbage Collection logs are presented as a practical, high‑signal window into how the JVM manages memory, transforming cryptic output into actionable diagnostics. The chapter shows how GC logs help uncover root causes behind slowdowns, spikes in CPU, stop‑the‑world pauses, and instability—illustrated by incidents where mis‑tuned heaps or unchecked thread growth led to aggressive Full GCs and service degradation. Beyond demystifying terminology and event types (young, mixed, full), it emphasizes a methodical approach to reading the logs and, when scale or volume makes manual review impractical, leveraging AI assistance to rapidly surface patterns and anomalies.

Practically, the chapter walks through enabling logging with -Xlog:gc* and redirecting output to files with time, uptime, level, and tags for reliable, structured analysis. It explains what initialization lines reveal (collector, JVM version, CPUs, heap and region sizes, worker counts) and how event logs expose phases and timings, tying them back to heap organization (Eden, Survivor, Old). For real‑world operations, it recommends storing logs separately, timestamping filenames, and configuring rotation (filecount, filesize) to prevent overwrites and bloat. It also offers guidance on choosing logging levels: errors/warnings in production to reduce overhead, info for routine visibility, and debug/trace only in controlled environments or focused investigations—optionally assisted by specialized tooling or AI to accelerate triage.

For analysis, the chapter centers on correlating pause durations, frequency, and before/after heap usage to diagnose performance lags, then distinguishing memory leaks (little reclaimed even after Full GC, monotonic growth) from insufficient memory (frequent but effective collections with sawtooth patterns). Remediation spans tuning heap sizing (Xms/Xmx), adjusting generation sizing and allocation behavior, selecting a suitable collector for latency goals (e.g., G1 vs low‑pause alternatives), and refining GC parallelism via -XX:ParallelGCThreads and -XX:ConcGCThreads to avoid both underutilization and CPU contention. The overarching message is iterative, evidence‑driven tuning: capture clean logs, read the right signals, validate hypotheses, and apply targeted changes while monitoring their real workload impact.

Enabling the GC logs in IntelliJ IDEA running configuration to display the GC logs in the execution console.

Adding a VM property to store GC logs for the application's execution in a specified file.

Properly formatted GC logs are stored in the specified file, as defined by the VM parameter.

Using tools such as GCeasy or AI chat assistants to help you troubleshoot the GC logs.

A comparison between the memory consumption graph of an application with normal memory usage and one affected by a memory leak.

• Garbage Collector logs are crucial for troubleshooting JVM memory management issues. They provide insights into memory allocation, garbage collection pauses, and heap utilization.
• Enabling GC logs is the first step in analyzing JVM memory behavior. The -Xlog:gc* VM option enables GC logging, helping developers track GC activity in real-time or store logs for later analysis.
• Understanding GC log structure is essential. Logs include details on GC events, pause times, heap size changes, and memory allocation patterns.
• GC logs help diagnose excessive GC pauses. Long GC pause times (typically above 50ms) can indicate performance issues, while frequent Full GC events suggest memory pressure.
• Heap memory organization impacts GC performance. Objects move through Eden, Survivor, and Old Generation memory regions. Inefficient memory usage can cause frequent GC interruptions.
• Frequent Full GC events may indicate insufficient memory or a memory leak. Logs showing frequent Full GC events with minimal memory reclamation suggest a leak, while effective but frequent Full GCs indicate an under-provisioned heap.
• Storing GC logs in files is recommended for deeper analysis. Use -Xlog:gc*:file=gc.log:time,uptime,level,tags to redirect logs to a file for structured storage and easier troubleshooting.
• Log rotation prevents excessive storage use. Configuring file count and file size limits ensures logs do not consume excessive disk space.
• Choosing the right logging level improves troubleshooting efficiency. Error logs capture critical failures, while Info and Debug levels provide additional insights into memory management.
• Tuning GC parallelism can reduce pause times. Adjusting -XX:ParallelGCThreads and -XX:ConcGCThreads optimizes CPU usage for better performance.
• AI tools and third-party services can simplify GC log analysis. Uploading logs to tools like GCEasy or using AI assistants can speed up troubleshooting.
